Reclaiming 1.1.1.1 For The Internet

Hopefully by now you’ve seen the announcement that CloudFlare has opened a new DNS service at the address of 1.1.1.1. We covered a bit of it on this week’s episode of the Gestalt IT Rundown. Next to Gmail, it’s probably the best April Fool’s announcement I’ve seen. However, it would seem that the Internet isn’t quite ready for a DNS resolver service that’s easy to remember. And that’s thanks in part to the accumulation of bad address hygiene.

Not So Random Numbers

The address range of 1/8 is owned by APNIC. They’ve had it for many years now but have never announced it publicly. Nor have they ever made any assignments of addresses in that space to clients or customers. In a world where IPv4 space is at a premium, why would a RIR choose to lose 16 million addresses?

Edit: As pointed out by Dale Carder of ES.net in a comment below, APNIC has been assigning address space out of 1 /8 since 2010. However, the most commonly leaked prefixes in that subnet that are difficult to assign because of bogus announcements come from 1.0.0.0/14.

As it turns out, 1/8 is a pretty bad address space for two reasons. 1.1.1.1 and 1.2.3.4. These two addresses are responsible for most of the inadvertent announcements in the entire 1/8 space. 1.2.3.4 is easy to figure out. It’s the most common example IP address given when talking about something. Don’t believe me? Google is your friend. Instead of using 192.0.2.0/24 like we should be using, we instead use the most common PIN, password, and luggage combination in the world. But, at least 1.2.3.4 makes sense.

Why is 1.1.1.1 so popular? Well, the first reason is thanks to Airespace wireless controllers. Airespace uses 1.1.1.1 as the default virtual interface address for just about everything. Here’s a good explanation from Andrew von Nagy. When Airespace was sold to Cisco, this became a very popular address for Cisco wireless networks. Except now that it’s in use as a DNS resolver there are issues with using it. The wireless experts I’ve talked to recommend changing that address to 192.0.2.1, since that address has been marked off for examples only and will never be globally routable.

The other place where 1.1.1.1 seems to be used quite frequently is in Cisco ASA failover interfaces. Cisco documentation recommended using 1.1.1.1 for the primary ASA failover and 1.1.1.2 as the secondary interface. The heartbeats between those two interfaces were active as long as the units were paired together. But, if they were active and reachable then any traffic destined for those globally routable addresses would be black holed. Now, ASAs should probably be using 192.0.2.1 and 192.0.2.2 instead. But beware that this will likely require downtime to reconfigure.

The 1.1.1.1 address confusion doesn’t stop there. Some systems like Nomadix use them as the default logout address. Vodafone used to use it as an image caching server. ISPs are blocking it upstream in some ACLs. Some security organizations even recommend dropping traffic to 1/8 as a bogon prevention measure. There’s every chance that 1.1.1.1 is going to be dropped by something in your network or along the transit path.

Planning Not To Fail

So, how are you going to proceed if you really, really want to use CloudFlare DNS? Well, the first step is to make sure that you don’t have 1.1.1.1 configured anywhere in your network. That means checking WLAN controllers, firewalls, and example configurations. Odds are good you’re running RFC1918 space. But you should try to ping 1.1.1.1 anyway. If you can ping it, then you should traceroute the address. If the traceroute leaves your local network, you probably have a good path.

Once you’ve determined that you’re capable of reaching 1.1.1.1, you need to test it first. Configure it on a test machine or VM and make sure it’s actually resolving addresses for you. Better safe than sorry. Once you know it’s really working like you want it to work, configure it on your internal DNS servers as a forwarder. You still want internal control of DNS thanks to things like Active Directory. But configuring it as a forwarder means you can take advantage of all the features CloudFlare is building into the system while still retaining anything you’ve done locally.


Tom’s Take

I’m glad CloudFlare and APNIC are reclaiming 1.1.1.1 for some useful purpose. CloudFlare can take the traffic load of all the horribly misconfigured systems in the world. APNIC can use this setup to do some analytics work to find out exactly how screwed up things are. I wouldn’t be shocked to see something similar happen to 1.2.3.4 in the future if this bet pays off.

I’ve been using 1.1.1.1 since April 2nd and it works. It’s fast and hasn’t broken yet, which is the best that you can hope for from a DNS server. I’m sure I’ll play around with some of the advanced features as they come online but for now I’m just happy that one of the most recognizable IP addresses in the world is working for me.

Can Routing Be Oversimplified?

I don’t know if you’ve had a chance to see this Reddit thread yet, but it’s a funny one:

We eliminated routing protocols from our network!

Short non-clickbait summary: We deployed SD-WAN and turned off OSPF. We now have a /16 route for the internal network and a default route to the Internet where a lot of our workloads were moved into the cloud.

Bravo for this networking team for simplifying their network to this point. All other considerations aside, does this kind of future really bode well for SD-WAN?

Now You See Me

As pointed out in the thread above, the network team didn’t really get rid of their dynamic routing protocols. The SD-WAN boxes that they put in place are still running BGP or some other kind of setup under the hood. It’s just invisible to the user. That’s nothing new. Six years ago, Ivan Pepelnjak found out Juniper QFabric was running BGP behind the scenes too.

Hiding the networking infrastructure from the end user is nothing new. It’s a trick that has been used for years to allow infrastructures to be tuned and configured in such a way as to deliver maximum performance without letting anyone tinker with the secret sauce under the hood. You’ve been using it for years whether you realize it or not. Have MPLS? Core BGP routing is “hidden” from you. SD-WAN? Routing protocols are running between those boxes. Moved a bunch of workloads to AWS/Azure/GCE? You can better believe there is some routing protocol running under that stack.

Making things complex for the sake of making them hard to work on is foolish. We’ve spent decades and millions of dollars trying to make things easy. If you don’t believe me, look at the Apple iPhone. That device is a marvel at hiding all the complexity underneath. But, it also makes it really hard to troubleshoot when things go wrong.

Building On Shoulders

SD-WAN is doing great things for networking. I can remember years ago the thought of turning up a multi-site IPSec VPN configuration was enough to give me hives, let alone trying to actually do it. Today, companies like Viptela, VeloCloud, and Silver Peak make it easy to do. They’re innovating on top of the stack instead of inside it.

So much discussion in the community happens around building pieces of the stack. We spend time and effort making a better message protocol for routing information exchange. Or we build a piece of the HTTP stack that should be used in a bigger platform. We geek out about technical pieces because that’s where our energy feels the most useful.

When someone collects those stack pieces and tries to make them “easy”, we shout that company down and say that they’re hiding complexity and making the administrators and engineers “forget” how to do the real work. We spend more time focusing on what’s hidden and not enough on what’s being accomplished with the pieces. If you are the person that developed the fuel injection system in a car, are you going to sit there and tell Ford and Chevrolet than bundling it into a automotive platform is wrong?

So, while the end goal of any project like the one undertaken above is simplification or reducing problems because of less complex troubleshooting it is not a silver bullet. Hiding complexity doesn’t make it magically go away. Removing all your routing protocols in favor of a /16 doesn’t mean your routing networking runs any better. It means that your going to have to spend more time trying to figure out what went wrong when something does break.

Ask yourself this question: Would you rather spend more time building out the network and understand every nook and cranny of it or would you rather learn it on the fly when you’re trying to figure out why something isn’t working the way that it should? The odds are very good that you’re going to put the same amount of time into the network either way. Do you want to front load that time? Or back load it?


Tom’s Take

The Reddit thread is funny. Because half the people are dumping on the poster for his decision and the rest are trying to understand the benefits. It surely was created in such a way as to get views. And that worked admirably. But I also think there’s an important lesson to learn there. Simplicity for the sake of being simple isn’t enough. You have to replace that simplicity with due diligence. Because the alternative is a lot more time spent doing things you don’t want to do when you really don’t want to be doing them.

Programming Unbound

I’m doing some research on Facebook’s Open/R routing platform for a future blog post. I’m starting to understand the nuances a bit compared to OSPF or IS-IS, but during my reading I got stopped cold by one particular passage:

Many traditional routing protocols were designed in the past, with a strong focus on optimizing for hardware-limited embedded systems such as CPUs and RAM. In addition, protocols were designed as purpose-built solutions to solve the particular problem of routing for connectivity, rather than as a flexible software platform to build new applications in the network.

Uh oh. I’ve seen language like this before related to other software projects. And quite frankly, it worries me to death. Because it means that people aren’t learning their lessons.

New and Improved

Any time I see an article about how a project was rewritten from the ground up to “take advantage of new changes in protocols and resources”, it usually signals to me that some grad student decided to rewrite the whole thing in Java because they didn’t understand C. It sounds a bit cynical, but it’s not often wrong.

Want proof? Check out Linus Torvalds and his opinion about rewriting the Linux kernel in C++. Spoiler alert – “C++ is a horrible language.” And it gets more colorful from there. Linus has some very valid points about C++ that have been debated by lots of communities for the past ten years. But the fact remains that he has decided that completely rewriting the entire kernel in C++ is an exercise in futility.

In today’s world, we’re faced with a multitude of programming languages fighting for our attention. We’re evolved past FORTRAN, COBOL, C, and C++. We now live a world of Python, C#, J#, R, Ruby, and dozens more. And those don’t even include the languages that aren’t low-level and are more scripting. Every one of these languages was designed to solve a particular problem. And every one of them is begging to be used.

But it’s not enough that we have ten ways to write a function today. What’s more troublesome is that we’ve forgotten why certain languages were preferred over others in the past. We’ve forgotten that things used to be done the way they were done because we had no other alternatives. I can remember studying for my Novell CNE and taking 50-649, wherein Novell kept referring to OSPF as an “expensive” protocol to use on a NetWare server. At the time that test was created, OSPF was expensive from a CPU cycle standpoint. If the server was doing other things besides running a routing protocol you might see a potential impact if the CPU was slowed. And having OSPF calculations interrupted because someone was doing an FTP transfer could be expensive indeed.

No Wasted Space

More to the point, when people are faced with a limitation they have to be creative and concise. And nowhere is that more apparent than in E.T. the Extraterrestrial for the Atari 2600. Infamously, Howard Scott Warshaw had just one month to write a video game that would go on to be blasted critically, considered one of the worst of all time, and be blamed for the Video Game Crash of 1983. Yet, as one fan discovered years later when he set out to “fix” the game’s code, as bad is it may have been it was very well coded. From the article:

…it’s unlikely that Howard Scott Warshaw (the developer) included some useless code for us to replace…

So, a programmer for an outdated video game system had a month to code a complex game and managed to do it in such a way as to leave very little empty space to insert code patches? And yet my Facebook app on my iPhone requires how much space?!?

All joking aside, the issue with E.T. wasn’t code quality. The problems with the game have been documented over the years, but almost no one blames Warshaw’s coding capabilities. That’s because Warshaw was working within his limitations. He couldn’t magically make the Atari 2600 cartridge bigger. He couldn’t increase the CPU size on the system. He worked within him limitations and made the best game that he could make.

Now, let’s look at an article about Open/R and see some of Facebook’s criticisms of OSPF and IS-IS:

We didn’t want to get bogged down in discussions over the lower-level protocol details, such as frame formatting and handshakes…

While it might sound heavyweight compared with OSPF and ISIS, which use their own “lightweight” transports, we haven’t found this to be an issue in modern networking hardware…

Whether or not they were intended to be taken as such, these are some pretty interesting knocks against OSPF and IS-IS. What Facebook is essentially saying is that they didn’t want to worry about building the low level parts of the messaging system, so they picked something off the shelf. They also built it to be more resource intensive than necessary because they didn’t need to compromise when running it on Six Pack and Wedge.

So long as your routers have ample CPU cycles and memory, Open/R will run just fine. But how many people out there are running a data center server board in their edge router? How many routers out there have to take a reduced BGP table because they don’t have enough memory to fit the entire global IPv4 routing table in memory, let alone IPv6? If resources are infinite and time is irrelevant than building your protocols the way you want is of no consequence. But as soon as you add constraints to the equation, like support for older hardware or limited memory, you have to start making compromises to make things work.


Tom’s Take

I’m not saying that Open/R is a bad routing protocol. I’m going to save that analysis for a later time. But I do take a bit of umbrage with Facebook’s idea that OSPF and IS-IS are a bit outdated simply because they were programmed for a different era. If they were really that inept they would have been replaced or expanded by now. The fact that twenty-somethings got a bug to rewrite a routing protocol because they could and threw all caution to the wind with regard to resource usage should be a cautionary tale to any programmer out there. Never assume that you have more space than you need. Train yourself to do more with less. And be ready to compromise in case the worst case scenario becomes reality.

Should We Build A Better BGP?

One story that seems to have flown under the radar this week with the Net Neutrality discussion being so dominant was the little hiccup with BGP on Wednesday. According to sources, sources inside AS39523 were able to redirect traffic from some major sites like Facebook, Google, and Microsoft through their network. Since the ISP in question is located inside Russia, there’s been quite a lot of conversation about the purpose of this misconfiguration. Is it simply an accident? Or is it a nefarious plot? Regardless of the intent, the fact that we live in 2017 and can cause massive portions of Internet traffic to be rerouted has many people worried.

Routing by Suggestion

BGP is the foundation of the modern Internet. It’s how routes are exchanged between every autonomous system (AS) and how traffic destined for your favorite cloud service or cat picture hosting provider gets to where it’s supposed to be going. BGP is the glue that makes the Internet work.

But BGP, for all of the greatness that it provides, is still very fallible. It’s prone to misconfiguration. Look no further than the Level 3 outage last month. Or the outage that Google caused in Japan in August. And those are just the top searches from Google. There have been a myriad of problems over the course of the past couple of decades. Some are benign. Some are more malicious. And in almost every case they were preventable.

BGP runs on the idea that people configuring it know what they’re doing. Much like RIP, the suggestion of a better route is enough to make BGP change the way that traffic flows between systems. You don’t have to be a evil mad genius to see this in action. Anyone that’s ever made a typo in their BGP border router configuration will tell you that if you make your system look like an attractive candidate for being a transit network, BGP is more than happy to pump a tidal wave of traffic through your network without regard for the consequences.

But why does it do that? Why does BGP act so stupid sometimes in comparison to OSPF and EIGRP? Well, take a look at the BGP path selection mechanism. CCIEs can probably recite this by heart. Things like Local Preference, Weight, and AS_PATH govern how BGP will install routes and change transit paths. Notice that these are all set by the user. There are not automatic conditions outside of the route’s origin. Unlike OSPF and EIGRP, there is no consideration for bandwidth or link delay. Why?

Well, the old Internet wasn’t incredibly reliable from the WAN side. You couldn’t guarantee that the path to the next AS was the “best” path. It may be an old serial link. It could have a lot of delay in the transit path. It could also be the only method of getting your traffic to the Internet. Rather than letting the routing protocol make arbitrary decisions about link quality the designers of BGP left it up to the person making the configuration. You can configure BGP to do whatever you want. And it will do what you tell it to do. And if you’ve ever taken the CCIE lab you know that you can make BGP do some very interesting things when you’re faced with a challenge.

BGP assumes a minimum level of competency to use correctly. The protocol doesn’t have any built in checks to avoid doing stupid things outside of the basics of not installing incorrect routes in the routing table. If you suddenly start announcing someone else’s AS with better metrics then the global BGP network is going to think you’re the better version of that AS and swing traffic your way. That may not be what you want. Given that most BGP outages or configurations of this type only last a couple of hours until the mistake is discovered, it’s safe to say that fat fingers cause big BGP problems.

Buttoning Down BGP

How do we fix this? Well, aside from making sure that anyone touching BGP knows exactly what they’re doing? Not much. Some Regional Internet Registrars (RIRs) require you to preconfigure new prefixes with them before they can be brought online. As mentioned in this Reddit thread, RIPE is pretty good about that. But some ISPs, especially ones in the US that work with ARIN, are less strict about that. And in some cases, they don’t even bring the pre-loaded prefixes online at the correct time. That can cause headaches when trying to figure out why your networks aren’t being announced even though your config is right.

Another person pointed out the Mutually Agreed Norms for Routing Security (MANRS). These look like some very good common sense things that we need to be doing to ensure that routing protocols are secure from hijacks and other issues. But, MANRS is still a manual setup that relies on the people implementing it to know what they’re doing.

Lastly, another option would be the Resource Public Key Infrastructure (RPKI) service that’s offered by ARIN. This services allows people that own IP Address space to specify which autonomous systems can originate their prefixes. In theory, this is an awesome idea that gives a lot of weight to trusting that only specific ASes are allowed to announce prefixes. In practice, it requires the use of PKI cryptographic infrastructure on your edge routers. And anyone that’s ever configured PKI on even simple devices knows how big of a pain that can be. Mixing PKI and BGP may be enough to drive people back to sniffing glue.


Tom’s Take

BGP works. It’s relatively simple and gets the job done. But it is far too trusting. It assumes that the people running the Internet are nerdy pioneers embarking on a journey of discovery and knowledge sharing. It doesn’t believe for one minute that bad people could be trying to do things to hijack traffic. Or, better still, that some operator fresh from getting his CCNP isn’t going to reroute Facebook traffic through a Cisco 2524 router in Iowa. BGP needs to get better. Or we need to make some changes to ensure that even if BGP still believes that the Internet is a utopia someone is behind it to ensure those rose colored glasses don’t cause it to walk into a bus.

An Opinion On Offense Against NAT

It’s been a long time since I’ve gotten to rant against Network Address Translation (NAT). At first, I had hoped that was because IPv6 transitions were happening and people were adopting it rapidly enough that NAT would eventually slide into the past of SAN and DOS. Alas, it appears that IPv6 adoption is getting better but still not great.

Geoff Huston, on the other hand, seems to think that NAT is a good thing. In a recent article, he took up the shield to defend NAT against those that believe it is an abomination. He rightfully pointed out that NAT has extended the life of the modern Internet and also correctly pointed out that the slow pace of IPv6 deployment was due in part to the lack of urgency of address depletion. Even with companies like Microsoft buying large sections of IP address space to fuel Azure, we’re still not quite at the point of the game when IP addresses are hard to come by.

So, with Mr. Huston taking up the shield, let me find my +5 Sword of NAT Slaying and try to point out a couple of issues in his defense.

Relationship Status: NAT’s…Complicated

The first point that Mr. Huston brings up in his article is that the modern Internet doesn’t resemble the one build by DARPA in the 70s and 80s. That’s very true. As more devices are added to the infrastructure, the simple packet switching concept goes away. We need to add hierarchy to the system to handle the millions of devices we have now. And if we add a couple billion more we’re going to need even more structure.

Mr. Huston’s argument for NAT says that it creates a layer of abstraction that allows devices to be more mobile and not be tied to a specific address in one spot. That is especially important for things like mobile phones, which move between networks frequently. But instead of NAT providing a simple way to do this, NAT is increasing the complexity of the network by this abstraction.

When a device “roams” to a new network, whether it be cellular, wireless, wired, or otherwise, it is going to get a new address. If that address needs to be NATed for some reason, it’s going to create a new entry in a NAT state table somewhere. Any device behind a NAT that needs to talk to another device somewhere is going to create twice as many device entries as needed. Tracking those state tables is complicated. It takes memory and CPU power to do this. There is no ASIC that allows a device to do high-speed NATing. It has to be done by a general purpose CPU.

Adding to the complexity of NAT is the state that we’re in today when we overload addresses to get connectivity. It’s not just a matter of creating a singular one-to-one NAT. That type of translation isn’t what most people think of as NAT. Instead, they think of Port Address Translation (PAT), which allows hundreds or thousands of devices to share the same IP address. How many thousands? Well, as it turns out about 65,000 give or take. You can only PAT devices if you have free ports to PAT them on. And there are only 65,636 ports available. So you hit a hard limit there.

Mr. Huston talks in his article about extending the number of bits that can be used for NAT to increase the number of hosts that can be successfully NATed. That’s going to explode the tables of the NATing device and cause traffic to slow considerably if there are hundreds of thousands of IP translations going on. Mr. Huston argues that since the Internet is full of “middle boxes” anyway that are doing packet inspection and getting in the way of true end-to-end communications that we should utilize them and provide more space for NAT to occur instead of implementing IPv6 as an addressing space.

I’ll be the first to admit that chopping the IPv6 address space right in the middle to allow MAC addresses to auto-configure might not have been the best decision. But, in the 90s when we didn’t have DHCP it was a great idea in theory. And yes, assigning a /48 to a network does waste quite a bit of IP space. However, it does a great job of shrinking the size of the routing table, since that network can be summarized a lot better than having a bunch of /64 host routes floating around. This “waste” echoes the argument for and against using a /64 for a point-to-point link. If you’re worried about wasting several thousand addresses out of a potential billion then there might be other solutions you should look at instead.

Say My Name

One of the points that gets buried in the article that might shed some light on this defense of NAT is Mr. Huston’s championing for Named Data Networking. The concept of NDN is that everything on the Internet should stop being referred to as an address and instead should be tagged with a name. Then, when you want to look for a specific thing, you send a packet with that name and the Internet routes your packet to the thing you want. You then setup a communication between you and the data source. Sounds simple, right?

If you’re following along at home, this also sounds suspiciously like object storage. Instead of a piece of data living on a LUN or other SAN construct, we make every piece of data an object of a larger system and index them for easy retrieval. This idea works wonders for cloud providers, where object storage provides an overlay that hides the underlying infrastructure.

NDN is a great idea in theory. According to the Wikipedia article, address space is unbounded because you just keep coming up with new names for things. And since you’re using a name and not an address, you don’t have to NAT anything. That last point kind of blows up Mr. Huston’s defense of NAT in favor of NDN, right?

One question I have makes me go back to the object storage model and how it relates to NDN. In an object store, every piece of data has an Object ID, usually a UUID of 32 bits or 64 bits. We do this because, as it turns out, computers are horrible at finding names for things. We need to convert those names into numbers because computers still only understand zeros and ones at their most basic level. So, if we’re going to convert those names to some kind of numeric form anyway, why should we completely get rid of addresses? I mean, if we can find a huge address space that allows us to enumerate resources like an object store, we could duplicate a lot of NDN today, right? And, for the sake of argument, what if that huge address space was already based on hexadecimal?

Hello, Is It Me URLooking For?

To put this in a slightly different perspective, let’s look at the situation with phone numbers. In the US, we’ve had an explosion of mobile phones and other devices that have forced us to extend the number of area codes that we use to refer to groups of phone numbers. These area codes are usually geographically specific. We add more area codes to contain numbers that are being added. Sometimes these are specific to one city, like 212 is for New York. Other times they can cover a whole state or a portion of a state, like 580 does for Oklahoma.

It would be a whole lot easier for us to just refer to people by name instead of adding new numbers, right? I mean, we already do that in our mobile phones. We have a contact that has a phone number and an email address. If we want to contact John Smith, we look up the John Smith we want and choose our contact preference. We can call, email, or send a message through text or other communications method.

What address we use depends on our communication method. Calls use a phone number. If you’re on an iPhone like me, you can text via phone or AppleID (email address). You can also set up a video call the same way. Each of these methods of contact uses a different address for the name.

With Named Data Networking, are we going to have different addresses for each resource? If we’re doing away with addresses, how are we going to name things? Is there a name registry? Are we going to be allowed to name things whatever we want? Think about all the names of videos on Youtube if you want an idea of the nightmare that might be. And if you add some kind of rigid structure in the mix, you’re going to have to contain a database of names somewhere. As we’ve found with DNS, having a repository of information in a central place would make an awfully tempting target. Not to mention causing issues if it ever goes offline for some reason.


Tom’s Take

I don’t think there’s anything that could be said to defend NAT in my eyes. It’s the duct tape temporary solution that never seems to go away completely. Even with depletion and IPv6 adoption, NAT is still getting people riled up and ready to say that it’s the best option in a world of imperfect solutions. However, I think that IPv6 is the best way going forward. With more room to grow and the opportunity to create unique IDs for objects in your network. Even if we end up going down the road of Named Data Networking, I don’t think NAT is the solution you want to go with in the long run. Drive a sword through the heart of NAT and let it die.

Cisco and Viptela – The Price of Development Debt

Cisco finally pulled themselves into the SD-WAN market by acquiring Viptela on Monday. Viptela was considered to be one of, if not the leading SD-WAN vendor in the market. That Cisco decided to pick them as an acquisition target isn’t completely surprising. But one might wonder why?

IWANna New Debt

Cisco’s premier strategy for SD-WAN up until last week was IWAN. This is their catch-all solution designed to take the various component pieces being offered by SD-WAN solutions and replicate them on Cisco hardware. IWAN has served as a vehicle for Cisco to push things like the APIC-EM solution, Cisco ONE licensing, and a variety of other enhanced technologies like NBAR and PfR.

Cisco has packaged these technologies together because they have spent a couple of decades building these protocols up to be the best at what they do in the industry. NBAR was the key to application QoS years ago. PfR and OER were the genesis of Cisco having the ability to intelligently route packets to destinations. These protocols have formed the cornerstone of their platform for many, many years.

So why is IWAN such a mess? If you have the best of breed technology built into a router that makes the packets fly across the Internet at lightning speeds how is it that companies like Viptela were eating Cisco’s lunch in the SD-WAN space? It’s because those same best-of-breed protocols are to blame for the jigsaw puzzle of IWAN.

If you are the product manager for a protocol like NBAR or PfR, you want it to be adopted by as many people as possible. Wide adoption guarantees you’re going to have a job tomorrow or even next year. The people working on EIGRP and OSPF are safe. But if you get left behind technologically, you’re in for rough seas. Just ask the folks that managed LANE. But if you can attach yourself to a movement that’s got some steam, you’re in the drivers seat.

At the same time, you want your protocol or product to be the best at what it does. And sometimes being the best means you don’t compromise. That’s great when you are the only thing running on the system. But when you’re trying to get protocols to work together to create something bigger, you often find that compromises are not just a good idea, they’re necessary. But how do you handle it when the product manager for NBAR and the product manager for IP SLA get into a screaming match over who is going to blink first?

Using existing protocols and products is a great idea because it means you don’t have to reinvent the wheel every time you design something. But, with that wheel comes the technical debt of development. Given the chance to reuse something that thousands, if not millions, of dollars of R&D has gone into, companies like Cisco will jump at the chance to get some more longevity out of a protocol.

Not Pokey, But Gumby

Now, lets look at a scrappy startup like Viptela. They have to build their protocols from the ground up. Maybe they have the opportunity of leveraging some open source projects or some basic protocol implementations to get off the ground. That means that they are starting from essentially square one. It also means they are starting off with very little technical and development debt.

When Viptela builds their application monitoring stack or their IPSec VPN stack, they aren’t trying to build the best protocol for every possible situation that could ever be encountered by a wide variety of customers. They are just trying to build a protocol that works. And not just a protocol that works on its own. They want a protocol that works with everything else they are building.

When you’re forced to do everything from scratch, you find that you avoid making some of the same choices that you were forced to make years ago. The lack of technical and development debt also means you can take a new direction with things. Don’t want to support pre-shared key IPSec VPNs? Don’t build it into the protocol. Don’t care to have some of the quirks of PfR? Build something different that meets your needs. You have complete control.

Flexibility is why SD-WAN vendors were able to dominate the market for the past two years. They were able to adapt and change quickly because they didn’t need to keep trying to make systems integrate on top the tech and dev debt they incurred during the product lifecycle. That lets them concentrate on features that customers want, not on trying to integrate features that management has decreed must be included because the product manager was convincing in the last QBR.


Tom’s Take

In the end, the acquisition of Viptela by Cisco was as much about reduction of technical and development debt in their SD-WAN offerings as it was trying to get ahead in the game. They needed something that could be used as-is without the need to rely on any internal development processes. I alluded to this during our Network Collective Off-The-Cuff show. Without the spin-out model available any longer, Cisco is going to have to start making tough decisions to get things like this done. Either those decisions are made via reduction of business units without integration or through larger dollar signs to acquire solutions to provide the cohesion they need.

Building Reliability

Systems are inherently reliable. Until they aren’t. On a long enough timeline, even the most reliable system will eventually fail. How you manage that failure says a lot about the way your build your system or application. So, why is it then that we’re so focused on failing?

Ten Feet Tall And Bulletproof

No system is infallible. Networks go down. Cloud services get knocked offline. Even Facebook, which represents “the Internet” for a large number of people, has days when it’s unreachable. When we examine these outages, we often find issues at the core of the system that cause services to be unreachable. In the most recent case of Amazon’s cloud system, it was a typo in a script that executed faster than it could be stopped.

It could also be a failure of the system to anticipate increased loads when minor failures happen. If systems aren’t built to take on additional load when the worst happens, you’re going to see bigger outages. That is a particular thorn in the side of large cloud providers like Amazon and Google. It’s also something that network architects need to be aware of when building redundant pathways to handle problems.

Take, for example, a recent demo during Aruba Atmosphere 2017. During the Day 2 keynote, CTO Partha Narasimhan wowed the crowd in the room when he disclosed that they had been doing a controller upgrade during the morning talk. Users had been tweeting, surfing, and using the Internet without much notice from anyone aside from the most technical wireless minds in the room. Even they could only see some strange AP roaming behavior as an indicator of the controllers upgrading the APs.

Aruba showed that they built a resilient network that could survive a simulated major outage cause by a rolling upgrade. They’ve done everything they can to ensure uptime no matter what happens. But the bigger question for architects and engineers is “why are we solving the problem for others?”

Why Dodge Bullets When You Don’t Have To?

As amazing as it is to build a system that can survive production upgrades with no impact on users, what are we really building when we create these networks? Are we encouraging our users to respect our technology advantage in the network or other systems? Are we telling our application developers that they can count on us to keep the lights on when anything goes wrong? Or are we instead sending the message that we will keep scrambling to prevent issues in applications from being noticeable?

Building a resilient network is easy. Making something reliable isn’t rocket science. But create a network that is going to stay up for a long, long time without any outages is very expensive and process intensive. Engineering something to never be down requires layers of exception handling and backup systems that are as reliable as their primary counterparts.

A favorite story from the storage world involves recovery. When you initially ask a customer what their recovery point objective (RPO) is in a system, the answer is almost always “zero” or “as low as you can make it”. When the numbers are put together to include redundant or dual-active systems with replication and data assurance, the price tag of the solution is usually enough to start a new round of discussion along the lines of “how reliable can you make it for this budget?”

In the networking and systems world, we don’t have the luxury of sticker shock when it comes to creating reliability. Storage systems can have longer RPOs because lost data is gone forever. Taking the time to ensure it is properly recovered is important. But data in transmission can be retransmitted. That’s at the heart of TCP. So it’s expected that networks have near-instantaneous RPOs for no extra costs. If you don’t believe that, ask yourself what happens when you tell someone the network went down because there’s only one router or switch connecting devices together.

Instead of making systems ultra-reliable and absolving users and developers from thought, networks and systems should be as reliable as they can be made without huge additional costs. That reliability should be stated emphatically without wiggle room. These constraints should inform developers writing code so that exception handling can be built in to prevent issues when the inevitable outage occurs. Knowing your limitations is the first step to creating an atmosphere to overcome them.

A lesson comes from the programmers of old. When you have a limited amount of RAM, storage, or compute cycles, you can write very tight code. DOS programs didn’t need access to a cloud worth of compute. Mainframes could execute programs written on punch cards. The limitations were simple and could be overcome with proper problem solving. As compute and memory resources have exploded, so too have code bases. Rather than giving developers the limitless capabilities of the cloud without restraint, perhaps creating some limits is the proper way to ensure that reliability stays in the app instead of being bolted on to the network.


Tom’s Take

We had a lot of fun recording this roundtable. We talked about Aruba’s controller upgrade and building reliable wireless networks. But I think we also need to make sure we’re aware that continually creating protocols and other constructs in the underlay won’t solve application programming problems. Things like vMotion set networking and application development back a decade. Giving developers a magic solution to avoid building proper exception handling doesn’t make better developers. Instead, it puts the burden of uptime back on the networking team. And we would rather build the best network we can instead of building something that can solve every problem that could every possibly be created.

Sorting Through SD-WAN

lightspeed

SD-WAN has finally arrived. We’re not longer talking about it in terms of whether or not it is a thing that’s going to happen, but a thing that will happen provided the budgets are right. But while the concept of SD-WAN is certain, one must start to wonder about what’s going to happen to the providers of SD-WAN services.

Any Which Way You Can

I’ve written a lot about SDN and SD-WAN. SD-WAN is the best example of how SDN should be marketed to people. Instead of talking about features like APIs, orchestration, and programmability, you need to focus on the right hook. Do you see a food processor by talking about how many attachments it has? Or do you sell a Swiss Army knife by talking about all the crazy screwdrivers it holds? Or do you simply boil it down to “This thing makes your life easier”?

The most successful companies have made the “easier” pitch the way forward. Throwing a kitchen sink at people doesn’t make them buy a whole kitchen. But showing them how easy and automated you can make installation and management will sell boxes by the truckload. You have to appeal the opposite nature that SD-WAN was created to solve. WANs are hard, SD-WANs make them easy.

But that only works if your SD-WAN solution is easy in the first place. The biggest, most obvious target is Cisco IWAN. I will be the first to argue that the reason that Cisco hasn’t captured the SD-WAN market is because IWAN isn’t SD-WAN. It’s a series of existing technologies that were brought together to try and make and SD-WAN competitor. IWAN has all the technical credibility of a laboratory full of parts of amazing machines. What it lacks is any kind of ability to tie all that together easily.

IWAN is a moving target. Which platform should I use? Do I need this software to make it run correctly? How do I do zero-touch deployments? Or traffic control? How do I plug a 4G/LTE modem into the router? The answers to each of these questions involves typing commands or buying additional software features. That’s not the way to attack the complexity of WANs. In fact, it feeds into that complexity even more.

Cisco needs to look at a true SD-WAN technology. That likely means acquisition. Sure, it’s going to be a huge pain to integrate an acquisition with other components like APIC-EM, but given the lead that other competitors have right now, it’s time for Cisco to come up with a solution that knocks the socks off their longtime customers. Or face the very real possibility of not having longtime customers any longer.

Every Which Way But Loose

The first-generation providers of SD-WAN bounced onto the scene to pick up the pieces from IWAN. Names like Viptela, VeloCloud, CloudGenix, Versa Networks, and more. But, aside from all managing to build roughly the same platform with very similar features, they’ve hit a might big wall. They need to start making money in order for these gambles to pay off. Some have customers. Others are managing the migration into other services, like catering their offerings toward service providers. Still others are ripe acquisition targets for companies that lack an SD-WAN strategy, like HPE or Dell. I expect to see some fallout from the first generation providers consolidating this year.

The second generation providers, like Riverbed and Silver Peak, all have something in common. They are building on a business they’ve already proven. It’s no coincidence that both Riverbed and Silver Peak are the most well-known names in WAN optimization. How well known? Even major Cisco partners will argue that they sell these two “best of breed” offerings over Cisco’s own WAAS solution. Riverbed and Silver Peak have a definite advantage because they have a lot of existing customers that rely on WAN optimization. That market alone is going to net them a significant number of customers over the next few years. They can easily sell SD-WAN as the perfect addition to make WAN optimization even easier.

The third category of SD-WAN providers is the late comers. I still can’t believe it, but I’ve been reading about providers that aren’t traditional companies trying to get into the space. Talk about being the ninth horse in an eight horse race. Honestly, at this point you’re better off plowing your investment money into something else, like Internet of Things or Virtual Reality. There’s precious little room among the existing first generation providers and the second generation stalwarts. At best, all you can hope for is a quick exit. At worst, your “novel” technology will be snapped up for pennies after you’re bankrupt and liquidating everything but the standing desks.


Tom’s Take

Why am I excited about the arrival of SD-WAN? Because now I can finally stop talking about it! In all seriousness, when the boardroom starts talking about things that means it’s past the point of being a hobby project and now has become a real debate. SD-WAN is going to change one of the most irritating aspects of networking technology for us. I can remember trying to study for my CCNP and cramming all the DSL and T1 knowledge a person could fit into a brain in my head. Now, it’s all point-and-click and done. IPSec VPNs, traffic analytics, and application identification are so easy it’s scary. That’s the power of SD-WAN to me. Easy to use and easy to extend. I think that the landscape of providers of SD-WAN technologies is going to look vastly different by the end of 2017. But SD-WAN is going to be here for the long haul.

Is The Rise Of SD-WAN Thanks To Ethernet?

Ethernet

SD-WAN has exploded in the market. Everywhere I turn, I see companies touting their new strategy for reducing WAN complexity, encrypting data in flight, and even doing analytics on traffic to help build QoS policies and traffic shaping for critical links. The first demo I ever watched for SDN was a WAN routing demo that chose best paths based on cost and time-of-day. It was simple then, but that kind of thinking has exploded in the last 5 years. And it’s all thanks to our lovable old friend, Ethernet.

Those Old Serials

When I started in networking, my knowledge was pretty limited to switches and other layer 2 devices. I plugged in the cables, and the things all worked. As I expanded up the OSI model, I started understanding how routers worked. I knew about moving packets between different layer 3 areas and how they controlled broadcast storms. This was also around the time when layer 3 switching was becoming a big thing in the campus. How was I supposed to figure out the difference between when I should be using a big router with 2-3 interfaces versus a switch that had lots of interfaces and could route just as well?

The key for me was media types. Layer 3 switching worked very well as long as you were only connecting Ethernet cables to the device. Switches were purpose built for UTP cable connectivity. That works really well for campus networks with Cat 5/5e/6 cabling. Switched Virtual Interfaces (SVIs) can handle a large amount of the routing traffic.

For WAN connectivity, routers were a must. Because only routers were modular in a way that accepted cards for different media types. When I started my journey on WAN connectivity, I was setting up T1 lines. Sometimes they had an old-fashioned serial connector like this:

s-l300

Those connected to external CSU/DSU modules. Those were a pain to configure and had multiple points of failure. Eventually, we moved up in the world to integrated CSU/DSU modules that looked like this:

ehwic-2-ports-t-1-e-1

Those are really awesome because all the configuration is done on the interface. They also take regular UTP cables instead of those crazy V.35 monsters.

cisco_v35_old_large

But those UTP cables weren’t Ethernet. Those were still designed to be used as serial connections.

It wasn’t until the rise of MPLS circuits and Transparent LAN services that Ethernet became the dominant force in WAN connectivity. I can still remember turning up my first managed circuit and thinking, “You mean I can use both FastEthernet interfaces? No cards? Wow!”.

Today, Ethernet dominates the landscape of connectivity. Serial WAN interfaces are relegated to backwater areas where you can’t get “real WAN connectivity”. And in most of those cases, the desire to use an old, slow serial circuit can be superseded by a 4G/LTE USB modem that can be purchased from almost any carrier. It would appear that serial has joined the same Heap of History as token ring, ARCnet, and other venerable connectivity options.

Rise, Ethernet

The ubiquity of Ethernet is a huge boon to SD-WAN vendors. They no longer have to create custom connectivity options for their appliances. They can provide 3-4 Ethernet interfaces and 2-3 USB slots and cover a wide range of options. This also allows them to simplify their board designs. No more modular chassis. No crazy requirements for WIC slots, NM slots, or any other crazy terminology that Cisco WAN engineers are all too familiar with.

Ethernet makes sense for SD-WAN vendors because they aren’t concerned with media types. All their intelligence resides in the software running on the box. They’d rather focus on creating automatic certificate-based IPsec VPNs than figuring out the clock rate on a T1 line. Hardware is not their end goal. It is much easier to order a reference board from Intel and plug it into a box than trying to configure a serial connector and make a custom integration.

Even SD-WAN vendors that are chasing after the service provider market are benefitting from Ethernet ubiquity. Service providers may still run serial connections in their networks, but management of those interfaces at the customer side is a huge pain. They require specialized technical abilities. It’s expensive to manage and difficult to troubleshoot remotely. Putting Ethernet handoffs at the CPE side makes life much easier. In addition, making those handoffs Ethernet makes it much easier to offer in-line service appliances, like those of SD-WAN vendors. It’s a good choice all around.

Serial connectivity isn’t going away any time soon. It fills an important purpose for high-speed connectivity where fiber isn’t an option. It’s also still a huge part of the install base for circuits, especially in rural areas or places where new WAN circuits aren’t easily run. Traditional routers with modular interfaces are still going to service a large number of customers. But Ethernet connectivity is quickly growing to levels where it will eclipse these legacy serial circuits soon. And the advantage for SD-WAN vendors can only grow with it.


Tom’s Take

Ethernet isn’t the only reason SD-WAN has succeeded. Ease of use, huge feature set, and flexibility are the real reasons when SD-WAN has moved past the concept stage and into deployment. WAN optimization now has SD-WAN components. Service providers are looking to offer it as a value added service. SD-WAN has won out on the merits of the technology. But the underlying hardware and connectivity was radically simplified in the last 5-7 years to allow SD-WAN architects and designers to focus on the software side of things instead of the difficulties of building complicated serial interfaces. SD-WAN may not owe it’s entire existence to Ethernet, but it got a huge push in the right direction for sure.

Cloud Apps And Pathways

jam

Applications are king. Forget all the things you do to ensure proper routing in your data center. Forget the tweaks for OSPF sub-second failover or BGP optimal path selection. None of it matters to your users. If their login to Seibel or Salesforce or Netflix is slow today, you’ve failed. They are very vocal when it comes to telling you how much the network sucks today. How do we fix this?

Pathways Aren’t Perfect

The first problem is the cloud focus of applications. Once our packets leave our border routers it’s a giant game of chance as to how things are going to work next. The routing protocol games that govern the Internet are tried and true and straight out of RFC 1771(Yes, RFC 4271 supersedes it). BGP is a great tool with general purpose abilities. It’s becoming the choice for web scale applications like LinkedIn and Facebook. But it’s problematic for Internet routing. It scales well but doesn’t have the ability to make rapid decisions.

The stability of BGP is also the reason why it doesn’t react well to changes. In the old days, links could go up and down quickly. BGP was designed to avoid issues with link flaps. But today’s links are less likely to flap and more likely to need traffic moved around because of congestion or other factors. The pace that applications need to move traffic flows means that they tend to fight BGP instead of being relieved that it’s not slinging their traffic across different links.

BGP can be a good suggestion of path variables. That’s how Facebook uses it for global routing. But decisions need to be made on top of BGP much faster. That’s why cloud providers don’t rely on it beyond basic connectivity. Things like load balancers and other devices make up for this as best they can, but they are also points of failure in the network and have scalability limitations. So what can we do? How can we build something that can figure out how to make applications run better without the need to replace the entire routing infrastructure of the Internet?

GPS For Routing

One of the things that has some potential for fixing inefficiency with BGP and other basic routing protocols was highlighted during Networking Field Day 12 during the presentation from Teridion. They have a method for creating more efficiency between endpoints thanks to their agents. Founder Elad Rave explains more here:

I like the idea of getting “traffic conditions” from endpoints to avoid congestion. For users of cloud applications, those conditions are largely unknown. Even multipath routing confuses tried-and-true troubleshooting like traceroute. What needs to happen is a way to collect the data for congestion and other inputs and make faster decisions that aren’t beholden to the underlying routing structure.

Overlay networking has tried to do this for a while now. Build something that can take more than basic input and make decisions on that data. But overlays have issues with scaling, especially past the boundary of the enterprise network. Teridion has potential to help influence routing decisions in networks outside your control. Sadly, even the fastest enterprise network in the world is only as fast as an overloaded link between two level 3 interconnects on the way to a cloud application.

Teridion has the right idea here. Alternate pathways need to be identified and utilized. But that data needs to be evaluated and updated regularly. Much like the issues with Waze dumping traffic into residential neighborhoods when major arteries get congested, traffic monitors could cause overloads on alternate links if shifts happen unexpectedly.

The other reason why I like Teridion is because they are doing things without hardware boxes or the need to install software anywhere but the end host. Anyone working with cloud-based applications knows that the provider is very unlikely to provide anything outside of their standard offerings for you. And even if they manage, there is going to be a huge price tag. More often than not, that feature request will become a selling point for a new service in time that may be of marginal benefit until everyone starts using it. Then application performance goes down again. Since Teridion is optimizing communications between hosts it’s a win for everyone.


Tom’s Take

I think Teridion is on to something here. Crowdsourcing is the best way to gather information about traffic. Giving packets a better destination with shorter travel times means better application performance. Better performance means happier users. Happier users means more time spent solving other problems that have symptoms that aren’t “It’s slow” or “Your network sucks”. And that makes everyone happier. Even grumpy old network engineers.

Disclaimer

Teridion was a presenter during Networking Field Day 12 in San Francisco, CA. As a participant in Networking Field Day 12, my travel and lodging expenses were covered by Tech Field Day for the duration of the event. Teridion did not ask for nor where they promised any kind of consideration in the writing of this post. My conclusions here represent my thoughts and opinions about them and are mine and mine alone.
