Running Barefoot – Thoughts on Tofino and P4

Posted on by
1

barefootgrass

The big announcement this week is that Barefoot Networks leaped out of stealth mode and announced that they’re working on a very, very fast datacenter switch. The Barefoot Tofino can do up to 6.5 Tbps of throughput. That’s a pretty significant number. But what sets the Tofino apart is that it also uses the open source P4 programming language to configure the device for everything, from forwarding packets to making routing decisions. Here’s why that may be bigger than another fast switch.

Feature Presentation

Barefoot admits in their announcement post that one of the ways they were able to drive the performance of the Tofino platform higher was to remove a lot of the accumulated cruft that has been added to switch software for the past twenty years. For Barefoot, this is mostly about pushing P4 as the software component of their switch platform and driving adoption of it in a wider market.

Let’s take a look at what this really means for you. Modern network operating systems typically fall into one of two categories. The first is the “kitchen sink” system. This OS has every possible feature you could ever want built in at runtime. Sure, you get all the packet forwarding and routing features you need. But you also carry the legacy of frame relay, private VLANs, Spanning Tree, and a host of other things that were good ideas at one time and now mean little to nothing to you.

Worse yet, kitchen sink OSes require you to upgrade in big leaps to get singular features that you need but carry a whole bunch of others you don’t want. Need routing between SVIs? That’s an Advanced Services license. Sure, you get BGP with that license too, but will you ever use that in a wiring closet? Probably not. Too bad though, because it’s built into the system image and can’t be removed. Even newer operating systems like NX-OS have the same kitchen sink inclusion mentality. The feature may not be present at boot time, but a simple command turns it on. The code is still baked into the kernel, it’s just loaded as a module instead.

On the opposite end of the scale, you have newer operating systems like OpenSwitch. The idea behind OpenSwitch is to have a purpose built system that does a few things really, really well. OpenSwitch can build a datacenter fabric very quickly and make it perform well. But if you’re looking for additional features outside of that narrow set, you’re going to be out of luck. Sure, that means you don’t need a whole bunch of useless features. But what about things like OSPF or Spanning Tree? If you decide later that you’d like to have them, you either need to put in a request to have it built into the system or hope that someone else did and that the software will soon be released to you.

We Can Rebuild It

Barefoot is taking a different track with P4. Instead of delivering the entire OS for you in one binary image, they are allowing you to build the minimum number of pieces that you need to make it work for your applications. Unlike OpenSwitch, you don’t have to wait for other developers to build in a function that you need in order to deploy things. You drop to an IDE and write the code you need to forward packets in a specific way.

There are probably some people reading this post that are nodding their heads in agreement right now about this development process. That’s good for Barefoot. That means that their target audience wants functionality like this. But Barefoot isn’t for everyone. The small and medium enterprise isn’t going to jump at the chance to spend even more time programming forwarding engines into their switches. Sure, the performance profile is off the chart. But it’s also a bit like buying a pricy supercar to drive back and forth to the post office. Overkill for 98% of your needs.

Barefoot is going to do well in financial markets where speed is very important. They’re also going to sell into big development shops where the network team needs pared-down performance in software and a forwarding chip that can blow the doors off the rest of the network for East <-> West traffic flow. Give that we haven’t seen a price tag on Tofino just yet, I would imagine that it’s priced well into those markets and beyond the reach of a shop that just needs two leaf nodes and a spine to connect them. But that’s exactly what needs to happen.

Tom’s Take

Barefoot isn’t going to appeal to shops that plug in a power cable and run a command to provision a switch. Barefoot will shine where people can write code that will push a switch to peak performance and do amazing things. Perhaps Barefoot will start offering code later on that gives you the ability to program basic packet forwarding into a switch or routing functions when needed without the requirement of taking hours of classes on P4. But for the initial release, keeping Tofino in the hands of dev shops is a great idea. If for no other reason than to cut down on support costs.

The 25GbE Datacenter Pipeline

Posted on by
Reply

pipeline

SDN may have made networking more exciting thanks to making hardware less important than it has been in the past, but that’s not to say that hardware isn’t important at all. The certainty with which new hardware will come out and make things a little bit faster than before is right there with death and taxes. One of the big announcements yesterday from Hewlett Packard Enterprise (HPE) during HPE Discover was support for a new 25GbE / 100GbE switch architecture built around the FlexFabric 5950 and 12900 products. This may be the tipping point for things.

The Speeds of the Many

I haven’t always been high on 25GbE. Almost two years ago I couldn’t see the point. Things haven’t gotten much different in the last 24 months from a speed perspective. So why the change now? What make this 25GbE offering any different than things from the nascent ideas presented by Arista?

First and foremost, the 25GbE released by HPE this week is based on the Broadcom Tomahawk chipset. When 25GbE was first presented, it was a collection of vendors trying to convince you to upgrade to their slightly faster Ethernet. But in the past two years, most of the merchant offerings on the market have coalesced around using Broadcom as the primary chipset. That means that odds are good your favorite switching platform is running Trident 2 or Trident 2+ under the hood.

With Broadcom backing the silicon, that means wider adoption of the specification. Why would anyone buy 25GbE from Brocade or Dell or HPE if the only vendor supporting it was that vendor of choice? If you can’t ever be certain that you’ll have support for the hardware in three or five years time, making an investment today seems silly. Broadcom’s backing means that eventually everyone will be adopting 25GbE.

Likewise, one of my other impediments to adoption was the lack of server NICs to ramp hosts to 25GbE. Having fast access ports means nothing if the severs can’t take advantage of them. HPE addressed this with the release of FlexFabric networking adapters that can run 25GbE Ethernet. More importantly, those adapters (and switches) can run at 10GbE as well. This means that adoption of higher bandwidth is no longer an all-or-nothing proposition. You don’t have to abandon your existing investment to get to 25GbE right away. You don’t have to build a lab pod to test things and then sneak it into production. You can just buy a 5950 today and clock the ports down to 10GbE while you await the availability and purchasing cycle to buy 25GbE NICs. Then you can flip some switches in the next maintenance window and be running at 25GbE speeds. And you can leave some ports enabled at 10GbE to ensure that there is maximum backwards compatibility.

The Needs of the Few

Odds are good that 25GbE isn’t going to be right for you today. HPE is even telling people that 25GbE only really makes sense in a few deployment scenarios, among which are large container-based hosts running thousands of virtual apps, flash storage arrays that use Ethernet as a backplane, or specialized high-performance computing (HPC) tricks with RDMA and such. That means the odds are good that you won’t need 25GbE first thing tomorrow morning.

However, the need for 25GbE is going to be there. As applications grow more bandwidth hungry and data centers keep shrinking in footprint, the network hardware you do have left needs to work harder and faster to accomplish more with less. If the network really is destined to become a faceless underlay that serves as a utility for applications, it needs to run flat out fast to ensure that developers can’t start blaming their utility company for problems. Multi-core server architectures and flash storage have solved two of the three legs of this problem. 25GbE host connectivity and the 100GbE backbone connectivity tied to it, solve the other side of the equation so everything balances properly.

Don’t look at 25GbE as an immediate panacea for your problems. Instead, put it on a timeline with your other server needs and see what the adoption rate looks like going forward. If server NICs are bought in large quantities, that will drive manufactures to push the technology onto the server boards. If there is enough need for connectivity at these speeds the switch vendors will start larger adoption of Tomahawk chipsets. That cycle will push things forward much faster than the 10GbE / 40GbE marathon that’s been going on for the past six years.

Tom’s Take

I think HPE is taking a big leap with 25GbE. Until the Dell/EMC merger is completed they won’t find themselves in a position to adopt Tomahawk quickly in the Force10 line. That means the need to grab 25GbE server NICs won’t materialize if there’s nothing to connect them. Cisco won’t care either way so long as switches are purchased and all other networking vendors don’t sell servers. So that leaves HPE to either push this forward to fall off the edge of the cliff. Time will tell how this will all work out, but it would be nice to see HPE get a win here and make the network the least of application developer problems.

Disclaimer

I was a guest of Hewlett Packard Enterprise for HPE Discover 2016. They paid for my travel, hotel, and meals during the event. While I was briefed on the solution discussed here and many others, there was no expectation of coverage of the topics discussed. HPE did not ask for, nor were they guaranteed any consideration in the writing of this article. The conclusions and analysis contained herein are mine and mine alone.

We Are Number Two!

Posted on by
Reply

Checklist

In my old IT life I once took a meeting with a networking company. They were trying to sell me on their hardware and get me to partner with them as a reseller. They were telling me how they were the number two switching vendor in the world by port count. I thought that was a pretty bold claim, especially when I didn’t remember seeing their switches at any of my deployments. When I challenged this assertion, I was told, “Well, we’re really big in Europe.” Before I could stop my mouth from working, I sarcastically replied, “So is David Hasselhoff.” Needless to say, we didn’t take this vendor on as a partner.

I tell this story often when I go to conferences and it gets laughs. As I think more and more about it the thought dawns on me that I have never really met the third best networking vendor in the market. We all know who number one is right now. Cisco has a huge market share and even though it has eroded somewhat in the past few years they still have a comfortable lead on their competitors. The step down into the next tier of vendors is where the conversation starts getting murky.

Who’s Number Two???

If you’ve watched a professional sporting event in the last few years, you’ve probably seen an unknown player in close up followed by an oddly specific statistic. Like Bucky has the most home runs by a left handed batter born in July against pitchers that thought The Matrix should have won an Oscar. When these strange stats are quoted, the subject is almost always the best or second best. While most of these stats are quoted by color announcers trying to fill airtime, it speaks to a larger issue. Especially in networking.

No one wants the third best anything. John Chambers is famous for saying during every keynote, “If Cisco can’t be number one or number two in a market we won’t be in it.” That’s easy to say when you’re the best. But how about the market down from there? Everyone is trying to position themselves as the next best option in some way or another. Number two by port counts. Number two by ports sold (which is somehow a different metric). Number two by units shipped or amount sold or some other way of phrasing things slightly differently in order to the viable alternative.

I don’t see this problem a lot in other areas. Servers have a clear first, second, and third order. Storage has a lot of tiering. Networking, on the other hand, doesn’t have a third best option. Yet there are way more than three companies doing networking. Brocade, HPE, Extreme, Dell, Cumulus Networks, and many more if you want to count wireless companies with switching gear for the purpose of getting into the Magic Quadrant. No one wants to be seen as the next best, next best thing.

How can we fix this? Well, for one thing we need impartial ranking. No more magical polygons and reports that take seventeen pages to say “It depends”. There are too many product categories that you can slice your solution into to be the best. Let’s get back to the easy things. Switches are campus or data center. Routers are campus or service provider. Hardware falls here or there. No unicorns. No single-product categories. If you’re the only product of your kind you are in the wrong place.

Tom’s Take

Once again, I think it’s time for a networking Consumer Reports type of publication. Or maybe something like Storage Review. We need someone to come in and tell vendors that they are the third or fourth best option out there by the following simple metrics. Yes, it’s very probable that said vendors would just ignore the ranking and continue building their own marketing bubble around the idea of being the second best switching platform for orange switches sold to school districts not named after presidents. Or perhaps finding out they are behind the others will spur people inside the company into actually getting better. It’s a faint hope, but hey. The third time’s a charm.

Aerohive Is Switching Things Up

Posted on by
2

Screen Shot 2013-03-03 at 12.01.20 PM

I’ve had the good fortune to be involved with Aerohive Networks ever since Wireless Field Day 1.  Since then, I’ve been present for their launch of branch routing.  I’ve also convinced the VAR that I work for to become a partner with them, as I believe that their solutions in the wireless space are of great benefit to my customer base.  It wasn’t long ago that some interesting rumors started popping up.  I noticed that Aerohive started putting out feelers to hire a routing and switching engineer.  There was also a routing and switching class that appeared in the partner training list.  All of these signs pointed to something abuzz on the horizon.

Today, Aerohive is launching a couple of new products.  The first of these is the aforementioned switching line.  Aerohive is taking their expertise in HiveOS and HiveManager and placing it into a rack with 24 cables coming out of it.  The idea behind this came when they analyzed their branch office BR100 and BR200 models and found that a large majority of their remote/branch office customers needed more than the 4 switch ports offered in those models.  Aerohive had a “ah ha” moment and decided that it was time to start making enterprise-grade switches.  The beauty of having a switch offering from a company like Aerohive is that the great management software that is already available for their existing products is now available for wired ports as well.  All of the existing polices that you can create through HiveManager can now be attached to an Aerohive switch port.  The GUI for port role configuration is equally nice:

Screen Shot 2013-03-03 at 4.14.11 PM

In addition, the management dashboard has been extended and expanded to allow for all kinds of information to be pulled out of the network thanks to the visibility that HiveManager has.  You can also customize these views to your heart’s content.  If you frequently find yourself needing to figure out who is monopolizing your precious bandwidth, you’ll be happy with the options available to you.

The first of three switch models, the SR2024, is available today.  It has 24 GigE ports, 8 PoE+ ports, 4 GigE uplinks, and a single power supply.  In the coming months, there will be two additional switches that have full PoE+ capability across 24 and 48 ports, redundant power supplies, and 10 GigE SFP+ uplinks.  For those that might be curious, I asked Abby Strong about the SFPs, and Aerohive will allow you to use just about anyone’s SFPs.  I think that’s a pretty awesome idea.

The other announcement from Aerohive is software based.  One of the common things that is seen in today’s wireless networks is containment of application traffic via multiple SSIDs. If you’ve got management users as well as end users and guests accessing your network all at once, you’ve undoubtedly created policies that allow them to access information differently.  Perhaps management has unfettered access to sites like Facebook while end users can only access it during break hours.  Guests are able to go where they want but are subject to bandwidth restrictions to prevent them from monopolizing resources.  In the past you would need three different SSIDs to accomplish something like this.  Having a lot of broadcasted SSIDs causes a lot of wireless congestion as well as user confusion and increased attack surface.  If only there was a way to have visibility into the applications that the users are accessing and create policies and actions based on that visibility.

Aerohive is also announcing application visibility in the newest HiveOS and HiveManager updates.  This allows administrators to peer deeply into the applications being used by users on the network and create policies on a per-user basis to allow or restrict them based on various criteria.  These policies follow the user through the network up to and including the branch office.  Later in the year, Aerohive will port these policies to their switching line.  However, when you consider that the majority of the users today are using mobile devices first and foremost, this is where the majority of the visibility needs to be.  Administrators can provide user-based controls and reporting to identify bandwidth hogs and take appropriate action to increase bandwidth for critical applications on the fly.  This allows for the most flexibility for both users and administrators.  In truth, it’s all the nice things about creating site-wide QoS policies without all the ugly wrench turning involved with QoS.  How could you not want that?

Tom’s Take

Aerohive’s dip into the enterprise switching market isn’t all that shocking.  They seem to be taking a page from Meraki and offering their software platform on a variety of hardware.  This is great for most administrators because once you’ve learned the software interface and policy creation, porting it between wired switch ports and wireless APs is seemless.  That creates an environment focused on solving problems with business decisions, not on problems with configuration guides.  The Aerohive switches are never going to outperform a Nexus 7000 or a Catalyst 4500.  For what they’ve been designed to accomplish in the branch office, however, I think they’ll fit the bill just fine.  And that’s something to be buzzing about.

Disclaimer

Aerohive provided a briefing about the release of these products.  I spoke with Jenni Adair and Abby Strong.  At no time did Aerohive or their representatives ask for any consideration in the writing of this post, nor were they assured of any of the same.  All of the analysis and opinions represented herein are mine and mine alone.
